Skid Mounted Pilot Plants

SMT
ll vessels are manufactured from S.S. 316 grade stainless steel sheets and are cGMP compliant construction. The vessels are Jacketed, insulated, cladded and with suitable agitator assembly in each vessel. Wax is melted in Wax melting vessel, Water is heated in water heating vessel. Both wax and water are transferred into the manufacturing vessel automatically through vacuum. In manufacturing vessel both wax and water are homogenized to make a uniform emulsion and cooled by passing chilled water into the jacket of manufacturing vessel. After the emulsion is formed active ingredients / colours etc are added and are thoroughly mixed & homogenized. Later necessary perfume is added in case of cosmetics or wherever necessary. Ointment / Cream is ready. The same is transferred by bump pump into the storage vessel. & from the storage vessel it is automatically transferred into the filling machine by means of metering pump. Flow rate of Metering pump can be set as per your tube filling machines speed and capacity.
Price : 20,00,000 INR
